Sun-Prime 6.2kW | PV 8500 Hybrid Solar Inverter

The Sun-Prime 6.2kW Hybrid Solar Inverter is a high-performance energy solution engineered for modern residential and light commercial applications. Designed with flexibility, reliability, and ease of use in mind, it combines a powerful 6200W inverter, advanced MPPT solar charger, and intelligent load management in a compact, IP65-rated enclosure.

This inverter supports battery-independent operation, offers dual AC output for optimized load control, and includes extensive communication interfaces for monitoring and integration with Battery Management Systems (BMS). With its ability to run in parallel with up to six units, it's ideal for scalable installations where power demands may grow over time.

Whether used in grid-tied, off-grid, or hybrid scenarios, the Sun-Prime 6.2kW delivers clean, reliable power with high efficiency, strong environmental resistance, and advanced safety features like GFCI, AFCI, and Rapid Shutdown.

Key Features

• Easy-to-Install, Reliable Design
  Simple setup and robust build for long-term, dependable operation in diverse environments.

• Selectable Input Voltage Range

  • 90–280V for home appliances

  • 170–280V for personal computers

• Dual AC Outputs
  Enables intelligent load management by separating critical and non-critical loads.

• Parallel Operation (Up to 6 Units)
  Scalable solution supporting system expansion and redundancy.

• IP65 Rated Enclosure
  Waterproof and dustproof, suitable for both indoor and outdoor installations.

• Battery-Independent Operation
  Can operate directly from solar and grid power even without battery connection.

• Replaceable Fan Design
  Easy maintenance for extended inverter lifespan.

• Advanced Communication Interfaces
  Equipped with RS485, RS232, CAN-BUS, USB, WiFi, Dry Contact, and BTS for comprehensive monitoring and control.

• Built-in Current Transformer (CT) Sensor
  Enables real-time energy consumption monitoring for self-consumption optimization.

• 2.8” Color LCD Touch Display
  Intuitive user interface with slide operation for enhanced usability.

• Safety & Protection Ready
  Supports optional Ground Fault Circuit Interruption (GFCI), Arc Fault Circuit Interruption (AFCI), and Rapid Shutdown for increased safety.

• External Battery Temperature Sensor (BTS)
  Monitors battery temperature to ensure safe and efficient charging.

• USB On-the-Go Support
  Simplifies firmware updates and allows for easy data logging.

Technical Specifications

Input

• Voltage: 230VAC

• Selectable Voltage Range:

  • 170–280V (PC mode)

  • 90–280V (Appliance mode)

• Frequency: 50Hz / 60Hz (Auto Sensing)

Output

• Rated Output: 6200W

• Surge Power: 22,000VA

• Voltage Regulation (Battery Mode): 230V ±5%

• Waveform: Pure Sine Wave

• Transfer Time:

  • 10ms (PC)

  • 20ms (Appliances)

• Peak Efficiency: 93%

Battery

• Battery Voltage: 48VDC

• Floating Charge Voltage: 54VDC

• Overcharge Protection: 63VDC

• Battery-Free Operation: Supported

Solar & AC Charging

• Charger Type: MPPT

• Max PV Array Power: 12,000W (6,000W x 2)

• MPPT Voltage Range: 90V – 450VDC

• Max PV Input Voltage: 500VDC

• Max PV Input Current: 27A x 2 (40A Max)

• Max Solar Charge Current: 150A

• Max AC Charge Current: 150A

• Max Total Charge Current: 150A

Physical

• Dimensions (D x W x H): 145mm x 438mm x 553.6mm

• Net Weight: 18.4 kg

• Enclosure Rating: IP65 (Outdoor Ready)

Communication & Interfaces

• Interfaces: USB, RS232, RS485, CAN-BUS, WiFi, Dry-contact, BTS

• External CT Sensor Port: Supported

• USB OTG: Supported

Environmental

• Operating Temperature: -10°C to 50°C

• Storage Temperature: -15°C to 60°C

• Humidity: 5% to 95% (non-condensing)

Certifications & Compliance

• Safety Standard: CE Certified

• Optional Protections: GFCI, AFCI, Rapid Shutdown

Parallel Capability

• Parallel Support: Yes, up to 6 units

• Application: Ideal for systems requiring high capacity or redundancy
